ข้อมูลเครื่อง
Frequency Response
USB DSD: 2Hz - 50kHz (-3dB)
USB PCM: 2Hz - 50kHz (-1.5dB)
CD: 2Hz - 20kHz
Harmonic distortion
USB DSD: 0.0006%
USB PCM 24bit: 0.0005%
CD: 0.0015%
Signal to Noise
USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 118dB
Dynamic range
USB DSD: 110dB
USB PCM 24bit: 118dBCD: 101dB
Line Output Level: 2.2Vrms
Headphone Output Level: 28mW / 32 ohms
Power Consumption
Powered on: 38W
Standby: 0.3W
Output Circuit: New HDAM + HDAM-SA2
Headphone Circuit: High slew rate op-amp + HDAM-SA2
H/P Amp Gain Setting: Yes (Low / Mid / High)
Disc Type
CD
CD-R (MP3 & WMA)
CD-RW (MP3 & WMA)
Fixed Analog Output (RCA): 1 (Gold Plated)
Optical input / output (Maximum Support): 0 / 1
Coaxial input / output (Maximum Support): 0 / 1
Headphone Output: 1
Remote Control Bus Terminal
Yes (RC-5 In / Out)
w/ External / Internal Select Switch
USB-A
1 (Front)
Mass Storage Class
5V/1A
Supported Audio File (USB)
MP3: Yes
WMA: Yes
AAC: Yes
WAV: Yes (~192kHz/24bit)
FLAC: Yes (~192kHz/24bit)
ALAC: Yes (~96kHz/24bit)
AIFF: Yes (~196kHz/24bit)
DSD (DIFF / DSF): Yes (~5.6MHz)
DSD Native Playback: Yes
Unit (W x H x D mm) 442 x 129 x 396
Net weight 7.5kg
Packaging Dimensions (W x H x D mm) 525×249×511
Panel Color Available Colors: Silver/Gold and Marantz Black
Front (Center) Panel Aluminum
